It is equipped with a unique feeding and Air Management System, the DSC-10/60iL Suction Collator provides optimum performance to feed a wide variety of paper types, weights, and sizes with superior efficiency and reliability. DSC-10/60iL is an ideal machine for every operator with its 10,000 sets/hour high speed processing and user friendliness.

     Duplo's long history Air Suction Collator further advanced with LED light communicating system to inform operator of the machine status quickly and visually. Blue LED light indicates when error happening. White LED lights up for visibility of loaded paper. Green/Red LED indicate to check running condition even from long distance.

     High resolution optical sensors check and validate the feeding accuracy and automatically divert any faulty sets into a reject tray without stopping or interrupting production.

      Up to 6 towers can be connected for a maximum of 60 bins. Divide the bins into 1/2, 1/3, and 1/4 blocks to allow reloading without having to stop or interrupt productivity. Use the interleaf mode to insert one or two sheets between a specified number of sheets or control each bin individually by using the IMBF (Intelligent Multi-Bin Feeding) to program the bins to perform customized feeding sequences.

     The DSF-2200 comes loaded with a number of high-end features including Duplo's own belt suction feed system, front and side air separation, an anti-static device and ultrasonic double feed detection for enhanced feed reliability.

     It feeds increased paper sizes up to 14" x 20" (or 9.05" x 24" via optional Extension Tray Kit) and offers a variety of options including a trail edge air kit, pre-loading kit, and 1D & 2D barcode readers.

     DSF-2200 sheet Feeder is the ideal solution for short and medium runs. DSF-2200 proudly offers superior feeding performance employing vacuum belt feeding mechanism, plus static eliminator device and air-knife sheet separation ensure accurate and consist feeding.

     The OMR (Optical Mark Recognition) devices detect the end of document even when each set has a different number of sheet. DSF-2200 is designed to feed pre-collated stock at 200 sheet/min. (maximum) to the downstream unit.

    DSF-6000 document sheet feeder is ideal for customers with medium to high production volume demands. It can process pre-collated digital or offset printed documents at a maximum production rate of 600 sheets per minute,which is able to connect systems of DBMS and DBM-600.

     Configurable with the DBM-600 Bookletmaker or iSaddle, the DSF-6000 Sheet Feeder offers the ultimate solution for converting pre-collated digital or offset printed media into high quality booklets at up to 4,500 per hour.

     Equipped with a technologically-advanced Air Management System, the DSF-6000 provides an unsurpassed level of high speed performance that ensures consistent feeding of a wide variety of paper types and weights, from 64 gsm to 300 gsm, at a speed of up to 600 sheets per minute.

     The main tray offers a loading capacity of 24” (610mm), which minimizes reloading by supporting longer run times. Three-side air separation and integrated static eliminator effectively handle the static common with digitally printed media. Optical and ultrasonic sensors accurately detect feed errors, should they occur.

Intelligent quality optimizer (option, RU – 518 is required for installation):

Skill less, Automated concentration adjustment and front / back register adjustment before printing in a short time. By greatly shortening the adjustment time, we will expand the original printing production of the machine. In addition, since concentration, front / back registration can be monitored in real time even during printing, high quality printed products can be stably supplied.

• Automated density correction – front and back register adjustment
• Real time gradation correction – front and back register adjustment

A wide range of paper and applications:

Excellent paper conveyance technology that stably feeds a wide variety of paper to a wide range of corresponding paper basis weight of 40 to 350 g / m ² . We will support business expansion by strengthening paper feedability such as offset printed paper, envelopes, mailing labels, etc. and identifying latent needs.

• 40gsm of thin paper , 350gsm can be printed on cardboard
• Air Suction feeding ( Optional )
• Low cost high quality envelop printing ( Optional )

Finisher - High function finisher that increases production efficiency (option):

Prepare a high-end finisher group that supports folding functions such as square backing, three-side cutting, crease function, saddle stitch binding, class max. 600 page case binding, quarter folding and fold folding. We will greatly contribute to reductions in personnel expenses and outsourcing expenses in CRD etc., short delivery time service, etc

•   T-shape type saddle stitching unit SD 513
•    Multi – Folding unit FD 503
•    Staple finisher FS 532 Type D

High efficiency workflow:

Strengthen various linking functions. It is possible to create a highly efficient and low-cost print workflow using AccurioPro Conductor and secure printing environment with authentication cooperation. In addition, with external software linkage, we provide efficient working environment using OpenAPI and IWS compatible software.

High resolution:

It provides exposure with 1200 dpi of LPH, smooth photographic image quality by adopting digital toner HD, CIE colour space, and high character quality. With excellent image quality, we offer high quality printed products for various purposes.

• High resolution output of 1200 dpi
• Digital Toner HD
• 9 patterns screen setting
• Adoption of CEI colour space

Function group supporting high quality:

Adjustable curl processing according to paper characteristics and output format, and optimum transfer method to produce high quality. In addition, image rotation and skew correction function are added for front and back registration, which greatly improves accuracy. It improves the quality of the final delivered goods as well as the workability of the post-processing process.

• Real time curl correction function ( Optional )
• Hybrid curl adjustment function ( Optional )
• Belt transfer method
• High – accuracy front and rear register adjustment function

High productivity · Excellent durability

High-speed color scanner is installed to productivity which becomes the highest class level with A3 size which is used frequently. In addition, it is robust design adopting a high rigidity frame and it works well even in a hard work site. Indeed, it boasts high level productivity and reliability as a production machine.

• High Speed output of A4: 136ppm , A3 : 78ppm
• Adopt high speed colour scanner
• Large capacity toner bottle
• Adoption of high rigidity body
• High feed / discharge capacity

Excellent operability:

A 15-inch large-size touch panel with excellent visibility and operability greatly improves working efficiency with unified UI display with colour machine. Furthermore, it carries advanced job management that supports operators, which leads to simplification of output work and labor saving.

Intelligent quality optimizer (option, RU – 518 is required for installation):

Skill less, Automated concentration adjustment and front / back register adjustment before printing in a short time. By greatly shortening the adjustment time, we will expand the original printing production of the machine. In addition, since concentration, front / back registration can be monitored in real time even during printing, high quality printed products can be stably supplied.

• Automated density correction – front and back register adjustment
• Real time gradation correction – front and back register adjustment

A wide range of paper and applications:

Excellent paper conveyance technology that stably feeds a wide variety of paper to a wide range of corresponding paper basis weight of 40 to 350 g / m ² . We will support business expansion by strengthening paper feedability such as offset printed paper, envelopes, mailing labels, etc. and identifying latent needs.

• 40gsm of thin paper , 350gsm can be printed on cardboard
• Air Suction feeding ( Optional )
• Low cost high quality envelop printing ( Optional )

Finisher - High function finisher that increases production efficiency (option):

Prepare a high-end finisher group that supports folding functions such as square backing, three-side cutting, crease function, saddle stitch binding, class max. 600 page case binding, quarter folding and fold folding. We will greatly contribute to reductions in personnel expenses and outsourcing expenses in CRD etc., short delivery time service, etc

•   T-shape type saddle stitching unit SD 513
•    Multi – Folding unit FD 503
•    Staple finisher FS 532 Type D

High efficiency workflow:

Strengthen various linking functions. It is possible to create a highly efficient and low-cost print workflow using AccurioPro Conductor and secure printing environment with authentication cooperation. In addition, with external software linkage, we provide efficient working environment using OpenAPI and IWS compatible software.

High resolution:

It provides exposure with 1200 dpi of LPH, smooth photographic image quality by adopting digital toner HD, CIE colour space, and high character quality. With excellent image quality, we offer high quality printed products for various purposes.

• High resolution output of 1200 dpi
• Digital Toner HD
• 9 patterns screen setting
• Adoption of CEI colour space

Function group supporting high quality:

Adjustable curl processing according to paper characteristics and output format, and optimum transfer method to produce high quality. In addition, image rotation and skew correction function are added for front and back registration, which greatly improves accuracy. It improves the quality of the final delivered goods as well as the workability of the post-processing process.

• Real time curl correction function ( Optional )
• Hybrid curl adjustment function ( Optional )
• Belt transfer method
• High – accuracy front and rear register adjustment function

High productivity · Excellent durability

High-speed color scanner is installed to productivity which becomes the highest class level with A3 size which is used frequently. In addition, it is robust design adopting a high rigidity frame and it works well even in a hard work site. Indeed, it boasts high level productivity and reliability as a production machine.

• High Speed output of A4: 136ppm , A3 : 78ppm
• Adopt high speed colour scanner
• Large capacity toner bottle
• Adoption of high rigidity body
• High feed / discharge capacity

Excellent operability:

A 15-inch large-size touch panel with excellent visibility and operability greatly improves working efficiency with unified UI display with colour machine. Furthermore, it carries advanced job management that supports operators, which leads to simplification of output work and labor saving.

Intelligent quality optimizer (option, RU – 518 is required for installation):

Skill less, Automated concentration adjustment and front / back register adjustment before printing in a short time. By greatly shortening the adjustment time, we will expand the original printing production of the machine. In addition, since concentration, front / back registration can be monitored in real time even during printing, high quality printed products can be stably supplied.

• Automated density correction – front and back register adjustment
• Real time gradation correction – front and back register adjustment

A wide range of paper and applications:

Excellent paper conveyance technology that stably feeds a wide variety of paper to a wide range of corresponding paper basis weight of 40 to 350 g / m ² . We will support business expansion by strengthening paper feedability such as offset printed paper, envelopes, mailing labels, etc. and identifying latent needs.

• 40gsm of thin paper , 350gsm can be printed on cardboard
• Air Suction feeding ( Optional )
• Low cost high quality envelop printing ( Optional )

Finisher - High function finisher that increases production efficiency (option):

Prepare a high-end finisher group that supports folding functions such as square backing, three-side cutting, crease function, saddle stitch binding, class max. 600 page case binding, quarter folding and fold folding. We will greatly contribute to reductions in personnel expenses and outsourcing expenses in CRD etc., short delivery time service, etc

•   T-shape type saddle stitching unit SD 513
•    Multi – Folding unit FD 503
•    Staple finisher FS 532 Type D

High efficiency workflow:

Strengthen various linking functions. It is possible to create a highly efficient and low-cost print workflow using AccurioPro Conductor and secure printing environment with authentication cooperation. In addition, with external software linkage, we provide efficient working environment using OpenAPI and IWS compatible software.

High resolution:

It provides exposure with 1200 dpi of LPH, smooth photographic image quality by adopting digital toner HD, CIE colour space, and high character quality. With excellent image quality, we offer high quality printed products for various purposes.

• High resolution output of 1200 dpi
• Digital Toner HD
• 9 patterns screen setting
• Adoption of CEI colour space

Function group supporting high quality:

Adjustable curl processing according to paper characteristics and output format, and optimum transfer method to produce high quality. In addition, image rotation and skew correction function are added for front and back registration, which greatly improves accuracy. It improves the quality of the final delivered goods as well as the workability of the post-processing process.

• Real time curl correction function ( Optional )
• Hybrid curl adjustment function ( Optional )
• Belt transfer method
• High – accuracy front and rear register adjustment function

High productivity · Excellent durability

High-speed color scanner is installed to productivity which becomes the highest class level with A3 size which is used frequently. In addition, it is robust design adopting a high rigidity frame and it works well even in a hard work site. Indeed, it boasts high level productivity and reliability as a production machine.

• High Speed output of A4: 136ppm , A3 : 78ppm
• Large capacity toner bottle
• Adoption of high rigidity body
• High feed / discharge capacity

Excellent operability:

A 15-inch large-size touch panel with excellent visibility and operability greatly improves working efficiency with unified UI display with colour machine. Furthermore, it carries advanced job management that supports operators, which leads to simplification of output work and labor saving.
